Free Standing Double Door Front Access


MKD, EKD SERIES
NEMA TYPE 12

Double Door Modular Enclosure



Application


Ralston’s MKD Series modular double door enclosures are designed to provide protection against dust, dirt and oil for items such as: electronic and electrical controls, instrumentation systems, pneumatic, hydraulic, machine controls as well as networking and telecommunications applications.



Ralston MKD series is designed around an advanced frame system with an abundance of features, options and accessories; make the MKD one of the worlds most used modular enclosure.



Construction



All MKD enclosures are made from 1.5mm mild steel and have continuously welded seems ground to a smooth finish.



Both 2mm steel doors are easily removed by pulling the removable hinge pins from the hidden hinges.  Doors are sealed with an extruded one-piece polyurethane gasket and secured closed with a 4 point locking system.  The standard DIN type 3mm pin lock can be replaced with optional locking inserts or a variety of swing handles.



The removable 3 piece bottom plates are made from 1.5mm steel.

The depth adjustable 3mm galvanized interior mounting panel is packaged on the exterior of the enclosure allowing quick and easy access for panel builders.



Finish


All enclosures are phosphatized and finished inside and out with RAL 7035 light grey polyester powder coating with a textured finish.



Standards


The MKD is built to the requirements of IP55, NEMA type 12 for industrial use, and type 13 for an oil and dust tight enclosure.



The MKD is CE, cUL, and UL approved.



Special Orders


Custom units made from stainless steel or with special finishes, sizes or punching can be supplied on order.

Part Number Height Width Depth Weight
EKD-12124 1200 mm 1200 mm 400 mm 112.00 kgs
MKD-16125-R5 1600 mm 1200 mm 500 mm 120.00 kgs
EKD-20125 2000 mm 1200 mm 500 mm 190.00 kgs
